ITech IT-M3140 Series User Manual

Quick Reference
1.7 Front Panel Menu Reference
This section lists the maps of all front panel menu, including Config menu, Sys-
tem menu, Protect menu and Function menu. For a brief tutorial, refer to 3.4
Use the Front Panel Menu.
1.7.1 Configuration Menu Reference
Press [Shift]+[V-set] (Config) to enter into the configuration menu interface.
Config Configuration menu
P-Set
Setting the power.
Mode
Set the output priority mode
CV Priority Voltage priority mode
CC Priority Current priority mode
V-Rise Time
Voltage rising time
Setting range: 0.025 to
10S.
When select CV priority, the menu
shows the two items.
V-Fall Time
Voltage falling time
Setting range: 0.025 to
10S.
I-Rise Time
Current rising time
Setting range: 0.025 to
10S.
When select CC priority, the menu
shows the two items.
I-Fall Time
Current falling time
Setting range: 0.025 to
10S.
Output Res
Set the internal resistance.
Timer
Set the output timer function.
Off
Turn the output timer off.
On
Turn the output timer on.
Time
Set the output time.
On Delay Set the output-on delay time.
Off Delay Set the output-off delay time.
Ext-Program
External Analog Function. This function is optional. The menu
can only display when corresponding board card is inserted. For
details, see 4.5 Analogue Function (Ext-Program) (Optional).
Copyright © Itech Electronic Co., Ltd.
8
