ITech IT-M3140 Series User Manual

Quick Reference
Latch
Latch mode. When the external Inhibit± control terminals de-
tects the level change from False to True, the power output will
be turned off. To release the latched state, you must first set
the external Inhibit± control port to the False state, and send a
command (OUTPut:PROTection:CLEar) to clear the corre-
sponding INH status bit.
Nomal
When Inhibit+ and Inhibit– are short-circuited, the
Inhibit± control port input is in the True state, and
if it is not short-circuited, it is in the False state.
Inverted
When Inhibit+ and Inhibit– are short-circuited, the
Inhibit± control port input is in the False state, and
if it is not short-circuited, it is in the True state.
System
Reset
Select whether to restore the factory default settings or not.
NO
Don’t restore the factory default settings.
YES
Restore the factory default settings.
System
Info
View the system information.
Model
Display the instrument model.
ArmVer
Display the control board version.
CommVer
Display the communication board version.
SN Display the serial number.
Last Cal Display last calibration date.
Run Time Display the instrument running time.
1.7.3 Protect Function Menu Reference
Press [Shift]+[Recall] (Protect) to enter into the configuration menu interface.
Protect Protection function menu
U-Max
The maximum output voltage setting value.
U-Min
The minimum output voltage setting value.
OVP
Over-voltage protection.
Off Turn the OVP function off.
On Turn the OVP function on.
Level
Over-voltage limit.
Delay Delay time.
OCP
Over-current protection.
Copyright © Itech Electronic Co., Ltd.
12
