Functions and Features
1. Press [Shift]+[I-set] (Function) to enter function menu interface.
2. Use left and right keys or rotate the knob to select List and press [Enter]
key to confirm.
3. Use left and right keys or rotate the knob to select Recall List and press
[Enter] key to confirm.
4. Use knob to select the list program to view and press [Enter] key to confirm.
5. Select List Setup and press [Enter] key to enter the view page of list file.
Use left and right keys or rotate the knob to view the following parameters.
• Mode: the operation mode for list program.
• End State: the running state after the list program is running over.
• Repeat: the number of list repetitions.
6. Select View Step and press [Enter] key to confirm.
7. Use knob to select the list step to view and press [Enter] key to confirm.
To the left of the slash is the desired step number to view and to the right of
the slash is the total steps number of the list program. At this point, the inter-
face displays all steps and automatically locates at the selected step.
8. Use knob or left and right keys to view all steps.
4.4.4 Run List Program
The user can run the existed list program as needed to enable outputting of cor-
responding waveform sequence by the power supply. Detailed operation steps
are as below:
1. Press [Shift]+[I-set] (Function) to enter function menu interface.
2. Use left and right keys or rotate the knob to select List and press [Enter]
key to enter the set interface of list mode.
3. Select the desired list program.
• Method 1: Select Recall List and press [Enter] key. Use knob to select
the desired list program and press [Enter] key to confirm.
• Method 2: To simplify the operation, you can directly run the list program
after editing it in the Edit List menu item. Skip the step in the Recall List
menu item.
4. Select Run List and press [Enter] key to confirm.
5. Use the knob to set Run List to On and press [Enter] key to confirm.
6. Press [On/Off] key to turn the output on.
7. Based on the trigger method, perform the trigger operation. When the trigger
signal is received, the power supply outputs the waveform sequences.
Stop running: During the running of List, you can press [Shift]+[I-set] (Func-
tion) to enter the Function menu and set the Run List as Off to stop running.
Otherwise, the List waveform cannot be edited while the List is running.
Copyright © Itech Electronic Co., Ltd.
61
