ITech IT-M3400 Series User Manual

Technical Specification
Max. current (rms） 1Aac (AC220)
DC Offset
-0.1A~+0.1A
Environment
Working temperature
0- 40 °C
Storage temperature
-20- 70℃
Noise 60dB
External temperature measurement
Measurement range
-20℃——120℃
Measurement accuracy
±1℃
Measurement resolution 0.1℃
Efficiency
Max. efficiency (Full-
load）
88%
Communication（Optional）
Communication interfaces
RS232/USB/RS485/CAN/LAN/GPIB/Analog
Mechanical parameters
Size and weight
450mm*214mm*43.5mm
Net weight 5kg
11.5 IT-M3423
Parameter IT-M3423 V1.2
Source Parameter
Rated value
( 0 ℃-40
℃)
Output Voltage
0-150V
Output Current
-12A~12A
Output Power
-400W~400W
Min. operating voltage
15V at -12A
CC
Range
-12A~12A
Setup Resolution
1mA
Accuracy
≤0.1%+0.1%FS
CV
Range
0-150V
Setup Resolution
10mV
Accuracy
<0.1% Umax
Copyright © Itech Electronic Co., Ltd.
118
