System-Related Functions
7.4.8 View the System Information
This menu item is used to view the system information of the instrument. The
procedures to view the system information are as follows.
1. Press composite keys [Shift]+[P-Set](System) to enter the System menu.
2. Rotate the knob to select System Info and press [Enter] to confirm.
3. Rotate the knob and view the system information.
Name Description
Model The instrument model
ArmVer The control board version
InvDspVer The DSP version
FpgaVer The Fpga version
CommVer The communication board version
SN The serial number
Mac The firmware address
Last Cal Last calibration date
Start Time Instrument running time
4. Press [Esc] to exit.
7.5 Measuring the DUT Temperature
This series instrument features temperature measuring terminals (Temp, GND),
is used to measure the DUT temperature. The operation procedures as
following:
1. Connecting the test line
a. Loosen the screws of the measuring temperature terminals, and insert
the thermocouple. Re-tighten the screws.
b. Connecting the other end of thermocouple to DUT.
2. Observe the information
a. Press the composite keys [Shift]+[P-set](System) to enter the system
menu.
b. Rotate the knob to select the External Meter and press [Enter] to
confirm.
c. The DUT temperature and total historical regenerative power are
displayed on screen.
1：UUT Temp
Copyright © Itech Electronic Co., Ltd.
81
