Technical Specification
Transient
Response
Time
Voltage
≤2mS
Output Protection range
OCP -6.2A or 6.2A
OVP 305V
OPP -210W or 210W
External analog (optional)
Voltage programming
External 0V~10V is 0~300V
Voltage monitoring
External 0V~10V is 0~300V
Current programming
External -10V~10V is -6A~6A
Current monitoring
External -10V~10V is -6A~6A
AC parameters
Voltage range
100VAC -240VAC
OVP 264VAC
UVP 90VAC
Frequency
47Hz~63Hz
Max. current (rms） 1Aac (AC220V)
DC Offset
-0.1A~+0.1A
Environment
Working temperature
0- 40 °C
Storage temperature
-20- 70℃
Noise 60dB
External temperature measurement
Measurement range
-20℃——120℃
Measurement accuracy
±1℃
Measurement resolution 0.1℃
Efficiency
Max. efficiency (Full-
load）
88%
Communication（Optional）
Communication interfaces
RS232/USB/RS485/CAN/LAN/GPIB/Analog
Mechanical parameters
Size and weight
450mm*214mm*43.5mm
Net weight 5kg
Copyright © Itech Electronic Co., Ltd.
125
