Load Function
The trigger method of the battery test is consistent with the trigger method
of the List function, that is, the List trigger source is also effective for the
Battery function.
If you want to stop running during the battery test, you can do the following:
Press the composite keys [Shift]+[I-set] (Function) on the front panel to enter
the function menu.
At this point, the interface will prompt whether to stop the running of the Func-
tion, you can press the Left/Right key to select Stop, then the current running
will be stopped, and the Function menu item will be displayed, you can re-enter
the Function menu for editing; if Reset is selected, it means to stop the present
running and return to the main interface to wait for the next trigger operation.
5.3 Protection Function
The series instrument provides the protection functions such as overcurrent,
overpower and undervoltage protection. The corresponding protection parame-
ters can be configured in the Protect menu.
Press [Shift]+[R-set] (Protect) to enter Protect menu interface. The descrip-
tions of protect menu are listed in the table below.
Protect Protection function menu
OCP
Overcurrent protection
Off Turn the OCP function off.
On Turn the OCP function on.
Level OCP limit
Delay Delay time
OPP
Overpower protection
Off Turn the OPP function off.
On Turn the OPP function on.
Level OPP limit
Delay Delay time
UVP
Undervoltage protection
Off Turn the UVP function off.
On Turn the UVP function on.
Level UVP limit
Delay Delay time
Copyright © Itech Electronic Co., Ltd.
132
