Power Supply Function

Function menu for editing; if Reset is selected, it means to stop the present run-

ning and return to the main interface to wait for the next trigger operation.

4.6.2 Battery Charging/Discharging Test Function

The IT6000B series power system provides the battery charging/discharging

test function based on its unique bipolar power supply properties. Suitable for

charging/discharging tests on all types of portable batteries.

Before performing the battery test, you need to connect the Sense ca-

bles to both ends of the battery. If the Sense cables are not con-

nected, the instrument cannot detect the Sense voltage and prompt

“Wait Power Link”, which will prevent the battery test from continuing.

BATTERY

Battery charging/discharging test function

Run

Indicates that the battery test mode is entered and

waits to trigger the running of the currently edited bat-

tery test file.

Edit

Edit the battery charging/discharging test file.

Charge /

Discharge

Set the test mode:

• Charge: Battery charging

• Discharge: Battery

discharging

According to the test require-

ments, choose one to set.

Charge /

Discharge

Set the voltage

value for charging

or discharging ac-

cording to the se-

lected test mode.

Charge /

Discharge I

Set the current val-

ue for charging or

discharging ac-

cording to the se-

lected test mode.
