Power Supply Function

Charge /

Discharge

Time

Set the charging

or discharging

time according to

the selected test

mode.

Cut Off Voltage Battery test cut-off voltage

Cut Off Current

Battery test cut-off current

Cut Off Capacity Battery test cut-off capacity

This instrument (in Source mode) supports battery discharge test in constant

current and constant power modes. If the user wants to discharge in constant

current mode, enter the Config menu, select the CC priority, set Vl to 0, set

Vh to the rated voltage value of the instrument, set P- to the rated power val-

ue of the instrument, and then set the Battery menu according to the test re-

quirements. If the user wants to discharge in constant power mode, set P- to

the specified value, and set Discharge V and Discharge I to the rated volt-

age and current value of the instrument.

1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-

ter the function menu.

2. Use knob or Up/Down key to select 2.BATTERY: Off and press [Enter].

The interface is displayed as follows:

FUNCTION BATTERY

Run Edit

3. Press the Left/Right key to select Edit and press [Enter].

4. Press the Left/Right key to select Charge or Discharge and press [Enter].

5. Set the charging voltage (Charge V) or discharging voltage (Discharge V),

charging current (Charge I) or discharging current (Discharge I) and the

other parameters, and then press [Enter] to confirm.

After the parameter setting is completed, the interface returns to the Battery

function main interface and displays as follows:

FUNCTION BATTERY

Run Edit

6. Press the Left/Right key to select Run and press [Enter].

The instrument will enter the battery test mode and wait for the battery test

to be triggered.
