Output Contro
l Command
s
Copyright © Itech Electronic Co., Lt
d.
28
Chapter7
Output Co
ntrol Commands
OUTPut[:ST
A
T
e]
This command is
used to turn on or
off the pow
er output.
Command synta
x
OUTPut[:S
T
A
T
e] <bool>
Parameters
off|on|
0|1
Query syntax
OUTPut[:S
T
A
T
e]?
38
40
Table of Contents
Default Chapter
3
Limitation of Warranty
3
Safety Signs
3
Warranty Service
3
Safety Precautions
4
Environmental Conditions
5
Regulation Tag
6
Waste Electrical and Electronic Equipment (WEEE) Directive
6
Compliance Information
7
Table of Contents
8
Chapter1 Remote Control
12
Overview
12
SCPI Command Introduction
12
Command Type of SCPI
12
Command Format
15
Data Type
17
Communication Interface
18
RS232 Interface
18
USB Interface
20
LAN Interface
20
GPIB Interface
20
Chapter2 System Commands
22
System:posetup
22
System:version
22
System:error
22
System:clear
23
System:remote
23
System:local
23
System:rwlock
24
System:beeper
24
System:communicate:gpib:rdevice:address
24
System:interface
25
System:preset
25
Status:questionable[:Event]
25
Status:questionable:condition
25
Status:questionable:enable<Enable Value
26
Status:questionable:ntransition
26
Status:questionable:ptransition
27
Status:operation[:Event]
27
Status:operation:condition
28
Status:operation:enable
28
Status:operation:ntransition
29
Status:operation:ptransition
29
Status:preset
29
Chapter3 Configuration Commands
30
Config[:Source]:Voltage[:Level]:Minimum
30
Config[:Source]:Voltage[:Level]:Maximum
30
Config[:Source]:Frequency:minimum
30
Config[:Source]:Frequency:maximum
31
Config:protect:current:rms
31
Config:protect:current:rms:mode
32
Config:protect:current:peak
32
Config:protect:current:peak:mode
32
Config:bnc[:Port][:Function]
33
Config:dimmer:mode
33
Config:list:start:mode
33
Config:measure:current:mode
34
Config:measure:current:range
34
[Source:]Protection:clear
34
Chapter4 Frequency Control Commands
35
[Source:]Frequency[:Immediate]
35
Chapter5 Phase Control Commands
36
[Source:]Phase:start
36
[Source:]Phase:end
36
[Source:]Dimmer[:Phase]
36
Chapter6 Voltage Control Commands
38
[Source:]Voltage[:Level][:Immediate][:Amplitude]
38
[Source:]Range
38
Chapter7 Output Control Commands
39
Output[:State]
39
Chapter8 Trace Subsystem Commands
40
Trace:clear
40
Trace:free
40
Trace:points
40
Trace:feed
41
Trace:feed:control
42
Trace:delay
42
Trace:timer
43
Trace:data
43
Chapter9 Measurement Commands
45
Fetch[:Scalar]:Voltage[:Ac]
45
Fetch[:Scalar]:Current[:Ac]
45
Fetch[:Scalar]:Power[:Ac][:Real]
45
Fetch[:Scalar]:Power[:Ac]:Apparent
45
Fetch[:Scalar]:Power[:Ac]:Pfactor
46
Fetch[:Scalar]:Frequency
46
Fetch[:Scalar]:Current[:Ac]:Peak
46
Fetch[:Scalar]:Current[:Ac]:Peak:maximum
46
Measure[:Scalar]:Voltage[:Ac]
46
Measure[:Scalar]:Current[:Ac]
47
Measure[:Scalar]:Power[:Ac][:Real]
47
Measure[:Scalar]:Power[:Ac]:Apparent
47
Measure[:Scalar]:Power[:Ac]:Pfactor
47
Measure[:Scalar]:Frequency
48
Measure[:Scalar]:Current[:Ac]:Peak
48
Measure[:Scalar]:Current[:Ac]:Peak:maximum
48
Measure
48
Fetch
48
Chapter10 List Operation Commands
49
List:state
49
List:recall
49
List:step:count
49
List:repeat
50
List:step:voltage
50
List:step:frequency
51
List:step:slope
51
List:step:dwell:unit
52
List:step:dwell
52
List:step:sd:state
53
List:step:sd:continue
53
List:step:sd:voltage
54
List:step:sd:site
54
List:step:sd:time
55
List:save:bank
55
List:run:step:count
56
List:run:step:repeat
56
Chapter11 Maximum Power Point Scanning Commands
57
Sweep:state
57
Sweep:recall
57
Sweep:start:voltage
57
Sweep:step:voltage
58
Sweep:end:voltage
58
Sweep:step:time:unit
58
Sweep:step:time
59
Sweep:start:frequecy
59
Sweep:step:frequecy
59
Sweep:end:frequecy
60
Chapter12 Trigger Commands
61
Trigger[:Immediate]
61
Trigger:source
61
Chapter13 Display Commands
62
Display[:Window][:State]
62
Display:text<Reference Value
62
Display:text:clear
62
Chapter14 Calibration Commands
63
Calibrate:secure:[State]
63
Calibrate:save
63
Calibrate:voltage:level
63
Calibrate:voltage [:Data] {<Numeric Value
64
Calibrate:current:level
64
Calibrate:current [:Data] {<Numeric Value
64
Calibrate:power:level
64
Calibrate:power [:Data] {<Numeric Value
65
Calibrate:string
65
Chapter15 IEEE488.2 Common Commands
66
Cls
66
Ese
66
Esr
67
Idn
67
Opc
67
Rst
68
Sre<Enable Value
68
Stb
68
Trg
69
Sav
69
Rcl
70
Wai
70
Tst
70
Opt
71
Appendixes
72
Register Description
72
