ITech IT7622 User Manual

Quick Start
Copyright ©ITECH Electronic Co., Ltd. 23
Key Symbol
Name & Function
Menu Edit: the programming items can be rolled by
operating the Up/Down key.
Prompts of corresponding
options are displayed on the right and options can be
selected via the soft key.
Digit Edit: the programming items can be rolled by
operating the Up/Down key. The digit to be edited is
selected by operating the Left/Right key or via the knob.
Carrying can be completed automatically.
Enter
Enter key, used for confirming the message
0～9
Number key. Enter the number directly
M1-M4
Recall the setup from internal memory stored in
Save1~4 for convenience. Press [Shift+M4] to exit
protection mode.
Enter/Lock
Enter key / keypad lock function keys，used to lock the
panel buttons
Esc
Cancel/Esc key
Used to delete the input digits in the digit editing mode.
On
Used for enabling the power function and input.
Off
Used for disabling the power function and input.
Setup/Menu
Setting key / Menu key，enter the System Menu and set
the configuration parameters of various functions
List/Step
List function key,edit the list file / Step function key
Recall/Save
Recall the setup from internal memory/ Store the AC
source settings in non-volatile memory.
Shift
Compound key，co-work with Lock/Menu/Step/Save and
M4.
/Meter
Basic metering key used for basic metering.
/Scope
Waveform Display key When this key is pressed,the
waveform
corresponding to current measurement data
will be displayed.
/Harmonic
Harmonic Measurement key When this key is pressed,
the harmonic measurement results and the menu of
harmonic measurement parameter configuration will be
displayed.
/Vector
Vector key When this key is pressed,the vector graph to
current measurement data will be displayed.
