Measurement Functions
Copyright ©ITECH Electronic Co., Ltd. 46
Chapter4 Measurement Functions
This chapter describes the characteristics and operations of the basic metering
function of IT7600 series source.
IT7600 series source has rich functions of basic metering of electric energy and
can accurately measure the parameters such as
Vrms, Irms, Ipeak, Idc, CF, PF
4.1 Interface Introduction
Press [Meter] on the front panel to enter the metering interface, as shown in
the figure below.
On: to enable the peak holding mode
Off: to disable the peak holding mode.
Disp: metering display interface
Conf: metering parameter configuration interface
4.2 Setup interface
Press [Meter] on the lower part of the screen, and then press [Conf] to enter
the metering parameter configuration interface, as shown in the figure below.
