13 Connecting the Headset Cable
Connecting the Headset Cable
Headset
1. Connects to voice cable end of voice cable
2. Headphones
3. Microphone
Connect the FC300 voice cable I/O connector to the I/O port on the FC300. The FC300 internal microphone
and speaker are automatically disabled.
Slide the voice cable ends together until they click shut. Do not twist or bend the connectors.
The FC300 is ready for voice-enabled applications.
WH-FC300USER-001 FC300 User Guide
For Review - Do Not Distribute - LXE Confidential
