17 Assemble the Carry Case
Assemble the Carry Case
Note: Itron recommends that accessory installation or removal be performed on a clean, well-lit surface.
When necessary, protect the work surface, the FC300, and components from electrostatic discharge.
1. Remove any cables connected to the I/O port at the bottom of the FC300.
2. Separate the hook and loop fabric on the carry case without removing the hook and loop fabric from the
carry case.
3. Slip the removable, clear plastic protector for the keypad and touchscreen into the case. Position it
against the openings for the keypad and touchscreen in the case. The voice case does not require the
clear plastic protector.
4. Slide the FC300 into the case, making sure the touchscreen and keypad (including the Scan LED) are
visible and accessible through the front openings of the case.
5. Securely tether the stylus to the case, if necessary. Place the stylus in the stylus holder on the hand-
strap or the trigger handle.
6. Loosen then tighten the handstrap (on cases without a trigger handle opening) until the carry case
assembly is secure in your hand.
7. When a shoulder strap is available,secure the clips at each end of the shoulder strap to the D rings on
either side of the carry case. The shoulder strap allows the FC300 to hang upside down until needed.
The main battery can be removed and inserted without taking the FC300 out of the carry case.
Carry Case with Metal Snaps
The metal snap has a bulge in the lip and a dot indentation on the opposite side. To snap the cap closed, tuck
the lip bulge under the snap lip and press on the dot to snap closed.
Pull the snap up to open.
WH-FC300USER-001 FC300 User Guide
For Review - Do Not Distribute - LXE Confidential
