ITRON SL7000 IEC7 - Meter Dimensions and Physical Size

User Guide SL7000 IEC7
74
9.3. Dimensions
The meter can be factory-fitted with either a short, standard or long terminal cover.
Meter dimensions - short terminal cover
Item Dimension Description
A 179 Meter body width
B 270 Meter length including terminal cover
C 83 Meter body depth
Meter dimensions - standard terminal cover
Item Dimension Description
B 324 Meter length including terminal cover
Meter dimensions - long terminal cover
Item Dimension Description
