2 EXTERNAL CLOCK
INCOHERENCE
A non-fatal alarm, where the RTC chip does not accept external
programming. If it occurs only once, it has little effect on the meters
time management.
3 CONFIGURATION
INCOHERENCE
Some possible causes for this alarm may be:
• An energy rate is used but quantity is not selected.
• Day is not defined from the weekly profile calendar.
• Incorrect scaler is selected from load profile channel.
The faults listed above do not normally occur as the support software
checks the configuration prior to saving.
4 PROGRAMMING
INCOHERENCE
This fault does not normally occur as the support software checks the
configuration prior to saving.
If after configuration programming this alarm appears it may mean the
previous configuration contained some different objects that are not
supported (or erased) by the new configuration.
5 CLOCK LOSS
BATTERY LOW ALARM
In case of clock loss, the meter takes the reference date of
01/01/1992 at midnight.
The RTC backup battery requires replacement and time/date will
need resetting.
10.3. MID display list
The MID display list will typically contain the following entries. However, further parameters may be included
depending on meter configuration, firmware revision and resource level.
Parameter Code Example value Unit
Active TER import phase 1 IMP PH1 00000000 Wh or kWh or MWh,
according active TER
group configuration
Active TER import phase 2 IMP PH2 00000000
Active TER import phase 3 IMP PH3 00000000
Active TER import aggregate IMP AGG 00000000
Active TER export phase 1 EXP PH1 00000000
Active TER export phase 2 EXP PH2 00000000
Active TER export phase 3 EXP PH3 00000000
Active TER export aggregate EXP AGG 00000000
MIDComplianceParameters
MID or
NOT MID
SAP MetEr ACE761
Internal firmware revision 5 11A INT REV
External firmware revision 5. 30C EXT REV
Internal checksum FFFFFFFF INT CHECK
External checksum FFFFFFFF EXT CHECK
Current connection parameters connEct DIRECT or
TRANSF
Energy active class
CLASS 02 or CLASS 05 or
CLASS 1 or CLASS A or
CLASS B or CLASS C
Current rating Iref 1.0 I REF I REF 1.0 A
