20
Adjusting the external rear view mirror
Press the (1) button to turn the mirror to the correct alignment in four basic settings (up, down, left, right).
To select the mirror to be adjusted, press the (2) button.
To activate central locking of the doors, press the (3) button.
Activation of the locking mechanism is indicated when the LED (4) is switched on.
If provided, the mirror symbols are shown on the display (for a maximum of 10 seconds after the last button was pressed) by
the mirror selected for adjustment being highlighted. The setting sequence for the mirrors selected for adjustment when
pressing the (2) button is as follows:
▪ Left main mirror;
▪ Left wide angle mirror;
▪ Right main mirror;
▪ Right wide angle mirror
ADJUSTING THE MIRROR
