11
Control instruments
1 Cruise control with LCD display
2 Indicator lights
3 LCD display
4 Speedometer with LCD display
5 Multifunction button:
▪ Press > 2 seconds to adjust the brightness of the display (3)
6 Engine coolant temperature
7 Fuel level indicator
8 Multifunction button:
▪ Press briefly
<
2 seconds to switch from total kilometres to trip mileage
▪ Long press
>
2 seconds deletes trip mileage
INSTRUMENT PANEL
General specifications. The driver is obligated to ensure that the conditions necessary
for their own safety and the safety of other road users are always fulfilled. If the
specification is not complied with, there is a significant health risk and the risk of
serious vehicle damage
NOTE: When the lights are switched on and the vehicle is moving backwards, the brightness of
the instrument panel is reduced in order to reduce reflections on the side window.
