Machine installation (schema)
FIG. 10 – MACHINE INSTALLATION (SCHEMA)
1. Power connection
2. USB cable
3. Pneumatic hose
4. Suction device
5. External compressed air supply
6. Data cable for PrograMill Suction Unit
7. Suction hose
Operating Instructions:PrograMill Dry
Version: 11/19/2020
PrograMill Dry – Installing the machine
EN 16
