Page #7 background image
No.
Description
7 x IR IN: Connect with IR receiver, fixed IR input for
the output, cannot be switched separately. It makes
up an IR bi-directional transmission with the IR OUT
on the corresponding HDBaseT receiver.
1 x IR EYE: Connect with extended IR receiver, use
the IR remote to control the Matrix Switcher.
8 x IR OUT: Plug in IR emitters to deliver the IR signal
sent from the far-end receivers connected to the
HDBaseT ports. These IR OUT sockets make up an
IR matrix with the IR IN sockets on the far-end
receivers, and all can be switched simultaneously with
the AV signal, or separately from switching. In default
setting, the 1~7 IR OUT corresponds with the 1~7 IR
IN, i.e. IR OUT1 - IR IN1, IR OUT2 - IR IN2, …IR
OUT7 - IR IN7.
1 x IR ALL OUT: Plug in IR emitter to deliver the IR
signal to control input source device form any of
far-end receivers.
RS232: Serial port for unit control, 3-pin pluggable
terminal block, connects with control device (e.g. PC).
TCP/IP: RJ45 port. Connect with PC for Web-based
GUI control.
SPDIF: Digital audio output connects directly via an
optic fiber cable to the Toslink input on a sound bar.
RCA (L&R): PCM Analogue audio output sockets
connect the de-embedded audio additional speakers.
Power port, connect with power cord.
PANEL DESCRIPTION
4
