JAC J2 User Manual



Maintenance Manual for J2 Sedan
Mechanical Part of Engine
124
8) Take off
the
Y
-ring.
Attention:
■ Tilt the fuel
pump
when it is taken
out,
so
as to avoid
broken of fuel level
sensor
.
■
T
o
avoid
residual
fuel
from
being
pollute
d,
wrap
the
Y
-ring
with
cloth to pull it out
straightly.
9) Take off
the
fuel
pump.
2. Check after
Dismantlement
1)
Fuel
pump
①

Visual
Inspection
■
Check
for broken
or
fuel
impurity.
If any
,
please
replace
or
wash
it.
②
 Inspect
Fuel
Pump
Operation
■
Actuate the
fuel pump
with 12V
regulated power
suppl
y directly
and check
if the
operation is
normal.
Attention:
■
Do not
make the fuel
pump operation
for a
long ti
me, so as to
avoid damage
of pump
plunger
.
2) Y-ring
■ Check it for material loss and
broken.
3) Locknut
■
Check
for
deformation, crack,
material
loss,
broken, and
damage
at
mounting
thread.
4)
Fuel
Level
Sensor
■ Check
the
fuel float
for int
erference
and o
xidation
of its surface.
3. Installation
Be aware of following precautions and install with steps contrary to dismantlement.
1)
Fuel
pump
assembly
Fig. 1.4.016
Fig. 1.4.015
