JAC J2 User Manual



Maintenance Manual for J2 Sedan
Mechanical Part of Engine
119
■
Insert
the
snap
slice C
into
the r
aised p
osition
B of
fuel p
ipe.
■
Make sure
the flange
A
of
fuel pipe
is pr
operly mounted in
the fixing
groove on
snap flange.
c.
Make
sure
the
fuel injector
will not
move
or fall
off. Installation is
completed.
3) Install fuel
pipe
guide rail
and fuel injector assembly inside intake
manifold.
Attention
:
■
Be
careful not
to
make
fuel
injector
nozzle contact
with other
parts.
4)
For
the
following steps,
install
with
steps
contrary to
dismantlement.
4. Check after Installation
Check for fuel
leakage with following steps.
1)
Set the
ignition switch at
“ON” position (when the
engine stops), and
then check
the connection
of
fuel pipe for leakage.
2)
Start the
engine, increase
its speed
and recheck
the connection
of fuel
pipe for
leakage.
V
.
Fuel
Filter
1. Dismantlement
Caution:
■ Do
read
the “General
Precautions” before
dealing with
fuel
system. Please
refer
to “General
Precaution
s”.
Attention
:
■ The
fuel
filter
should be
periodica
lly
replaced in
accordanc
e
with
the
maintenance instruction
specified in “User’
s Manual”.
1) Open
the
fuel
filler cap.
2)
Release
the
pressure
in
fuel
tank.
3)
Dismount
the
rear seat
cushion.
Please
refer
to “Rear Seat”.
4)
Dismount
the
service
lid
for
fuel
tank.
■
Directly
prize
it
up
with
flat
end
screwdriver.
Fig. 1.4.006
