1. Description
1) Intake absolute
pressure sensor (MAP)
is a
pressure sensitive variable
resistor.
Diaphragm inside
of
sensor is connected with a magnet core placed through the coil. When intake pipe pressure changes,
the diaphragm will drive the core to movement and thus change output voltage of sensor .With
sensor output voltage, ECU can determine engine intake volume, with which and reference to other
signals, injection volume control is achieved. .MAP sensor is also used to measure atmospheric
pressure during start
ing; under cert
ain condit
ions, it allows the EC
M to be adjust
ed automa
tically a
t
different altitudes. ECM provides 5V voltage to MAP sensor and receives voltage signal by the
signal line. The sensor is grounded with a wire from its variable resistor. MAP sensor input signal
affects ECM fuel output and ignition timing control.
2)
Intake temperature
sensor element
is
a
thermistor with
negative temperature
coefficient (NTC).
Its
resistance increases with the intake air temperature decreases. Engine ECU detects intake air
temperature changes via a contrast circuit.
2.
Installati
on
Position
Installed on the back of throttle
3.
Circuit
Diagram
Pin 19: 5V voltage signal
Pin 59: Manifold pressure sensor signal
Pin 40: Power ground
Pin 25: Intake air temperature sensor signal
Operating voltage: 5 ± 0.1V
Fig. 4.3.001
I
n
t
a
k
e
p
r
e
s
s
u
r
e
/
t
e
m
p
e
r
a
t
u
r
e
s
e
n
s
o
r
5V power supply 1
Sensor grounding
