JAC J2 User Manual



Maintenance Manual for J2 Sedan
Electronic Control System
of Engine
188
②
Unscrew fixing bolts, remove the sensor.
2
）

Installati
on
Be aware of following precaution to install with steps contrarily.
■
Be
aware
of
installation
gap.
Standard: 0.5 - 1.5mm
■ Tightening
torque:
7.8 - 9
N
• m
V
. Camshaft phase sensor
1. Component Description
This sensor provides crankshaft phase information to the ECU, namely differentiating the
compression top dead center and the exhaust top dead center of the crankshaft.
This sensor is manufactured by means of the Hall theory in which the Hall voltage is subject to the
varying magnetic field
induction strength.
Fig. 4.3.010
Fig. 4.3.011
