JAC J2 User Manual



Maintenance Manual for J2 Sedan
Electronic Control System
of Engine
224
S/N
Step
Check
result
Subsequent
step
always between 9V and 16V within
different rotation speed ranges.
No
Replace the
generator
Y
es
Diagnosi
s
help
4
Check
if
the
grounding
point
of
engine
harness is
good.
No
Repair or replace
the harness
Fault code: P0602 “the programming of electronic control unit is in trouble”
S/N
Step
Check
result
Subsequent
step
1
Connect the diagnosis device and adapter, and turn the ignition switch
to ON position.
Next step
Y
es
Next
step
2
Eliminate
the
fault
code
and
reconfirm
if
this
fault
is
a
steady
fault.
No
The system is
normal.
3
Replace
ECU.
End
Fault code: P0645 “the control circuit of A/C compressor relay is open”
S/N
Step
Check
result
Subsequent
step
1
Connect the diagnosis device and adapter, and turn the ignition switch
to OFF position.
Next step
Y
es To Step
4
2
Unplug the A/C compressor relay, turn the ignition key to “ON”
position, and check if the voltage between the relay power supply
side (namely Pins 87# and 85# of relay) and the negative pole of
power source is about 12V.
No
Next step
Yes
Repair or replace
the harness
3
Check if the circuit of relay power supply side is open or short to
ground.
No
T
o Step 2
Y
es
Replace
the
relay
4
Check if the voltage between the control side of A/C compressor
relay (namely Pin 86# of relay)
and the negative pole of pow
er source
is about 3.7V.
No
Next step
Yes
Repair or replace
the harness
5
Check if the circuit connecting control side of A/C compressor relay
(namely Pin 86# of relay) to Pin 61# of ECU is
open.
No
Diagnosis help
Fault code: P0646 “the control circuit of A/C compressor relay is short to ground”
S/N
Step
Check
result
Subsequent
step
1
Connect the diagnosis device and adapter, and turn the ignition switch
to OFF position.
Next step
Y
es
To
Step
4
2
Unplug the A/C compressor relay, turn the ignition key to “ON”
position, and check if the voltage between the relay power supply
side (namely Pins 87# and 85# of relay) and the negative pole of
power source is about 12V.
No
Next step
3
Check if the circuit of relay power supply side is open or short to
ground.
Yes
Repair or replace
the harness
