JAC J2 User Manual



Maintenance Manual for J2 Sedan
Mechanical Part of Engine
59
Attention
:
■
Handle
with
care
to
avoid
collision
or
damage.
⑦

Remove
the
camshaft
from
cylinder he
ad.
2
）

Disassembly of
balance
shaft
On the basis of above-mentioned disasse
mbly
procedure of c
amshaft, pro
ceed as b
elow:
Remove the bolts of balance shaft front end
cap and remove the balance shaft front end
cap.
①
■ Tightening torque for balance shaft front end
cap: 7.6±0.5N.m
②

Remove
the balance shaft idler gear,
remove
the bolts of balance shaft front gear, and
remove the balance shaft gear.
■
Tightening
torque
for
bolts
of
balance shaft
front gear: 23.5±4.5N.m
③

Remove the
bolts of
exhaust
bracket II
and
balance shaft side cover and remove the
balance shaft.
■
Tighten
ing torqu
e for
bolts of
cover:
7.6±0.6N.m
Fastening bolts for exhaust pipe bracket II:
22.5±2.5N.m
Fig.1.1.037
Fig.1.1.036
Fig.1.1.035
