Distance between intake camshaft base
circle
and valve tappet L1
Top end thickness of
mechanical tappet
Mechanical tappet
label
Valve clearance
(mm)
3.13
＜L1≤3.15
2.92
292 0.19-0.25
3.15
＜
L1≤3.17
2.94
294 0.19-0.25
3.17
＜
L1≤3.19
2.96
296
0.19-0.25
3.19
＜
L1≤3.21
2.98
298
0.19-0.25
3.21
＜L1≤3.23 3.00 300 0.19-0.25
3.23
＜
L1≤3.25 3.02 302 0.19-0.25
3.25
＜
L1≤3.27
3.04
304
0.19-0.25
3.27
＜
L1≤3.29
3.06 306 0.19-0.25
3.29
＜
L1≤3.31 3.08 308 0.19-0.25
3.31
＜
L1≤3.33
3.10
310
0.19-0.25
3.33
＜
L1≤3.35
3.12
312
0.19-0.25
3.35
＜
L1≤3.37 3.14 314 0.19-0.25
3.37
＜
L1≤3.39 3.16 316 0.19-0.25
3.39
＜
L1≤3.41
3.18
318
0.19-0.25
3.41
＜
L1≤3.43
3.20
320
0.19-0.25
3.43
＜
L1≤3.45 3.22 322 0.19-0.25
3.45
＜
L1≤3.47 3.24 324 0.19-0.25
3.47
＜
L1≤3.49
3.26
326
0.19-0.25
3.49
＜
L1≤3.51
3.28
328
0.19-0.25
3.51
＜L1≤3.53 3.30 330 0.19-0.25
Table: Distance between intake camshaft base circle and top of valve tappet, top end thickness of the
mechanical tappet grouping and assembly
