-4-
C.针杆部件/Needle bar mechanism
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 40622005 防震橡胶垫 Rubber cap,4.2
1
2 101S11005 螺钉 Screw,SM3.57
1
3 40626001 挑线连杆销 Thread take-up lever pin
1
4 40605002 挑线连杆 Thread take-up lever
1
5 40626002 针杆连接轴 Needle bar connecting shaft
1
6 10124001 挑线杆滚针轴承
Upper thread take-up needle bearing
1
7 10112003 针杆曲柄护板 Washer
1
8 40609001 针杆滑块 Needle bar guide slide block
1
9 40601002 针杆滑块座 Needle bar guide
1
10 201S11009 螺钉 Screw,pan SM3.57-40×6
2
11 40602009 针杆 Needle bar
1
12 40603002 针杆上套 Needle bar bush,U
1
13 40603003 针杆下套 Needle bar bush,D
1
14 40604001 针杆曲柄 Thread take-up crank,MH
1
15 409S14001 螺钉 Screw,SM6.35
2
16 116S14005 螺钉 Screw,SM6.35
3
17 40622006 橡皮塞 Needle bar cork
1
18 40622014 油封 Oil cup
1
19 10123002 针杆上毡塞 Clutch felt
1
20 10127015 回油毡夹 Wick nipper
1
21 12923018 油线 4×4(进口) Oil line
1
22 10112053 油线夹 Oil wick nipper
1
23 40604003 针杆曲柄 Thread take-up crank,H
1
24 409S14003 螺钉 Set screw,(CP)SM6.35
2
D1.抬压脚部件（9270D）/Presser bar mechanism(9270D)
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 40602002 压脚轴 Presser bar
1
2 406S30002 压力调节螺钉 Adjust screw
1
3 40603004 压脚轴套 Adjust screw bar
1
4 40609002 压杆导架 Adjust screw bar clamp
1
5 402S14006 螺钉(进口) Screw(import)
1
6 40627001 弹簧 Spring
1
7 40612004 抬压脚架 Presser bar lifter
1
8 406S20001 轴径螺钉 Shoulder screw,SM5.95
1
9 300258 抬压脚杠杆 Knee lifter lever
1
10 406S20002 杠杆螺钉 Shoulder screw,SM7.94
1
11 40627002 抬压脚架弹簧 Twist spring
1
12 300259 面板 Pace plate
1
13 40622007 面板垫 Packing
1
14 406S11009 螺钉 Screw,pan SM4.37-40×10
4
15 40611002 挡板 Front lid
1
16 101S11007 右线勾螺钉 Screw
2
17 40122017 橡皮塞 Rubber cap
1
18 40122005 橡皮塞 Rubber cap
1
19 40122017 橡皮塞 Rubber cap
1
