Jack JK-T9280D User Manual

-18-
L2.上线过线部件（9280D）/Upper threading mechanism(9280D)
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 4061204400 面线导线架支架板
Upper thread guide
1
2 40613001 过线勾
Thread guide
1
3 402S11022 螺钉
Screw,pan SM3.57-40×5
1
4 406S11018
螺钉 SM3/16×28
Screw,SM3/16×28
1
5 300264 面线松线器座
Upper thread tension bracket
1
6 4061304000 夹线器组件
yarn trapper assy
2
7 40602007 松线轴
Tension release shaft
1
8 406S30007 螺钉
Set screw,SM4.37
1
9 201S16003 螺母
Nut,SM4.37
1
10 40604016 松线曲柄
Tension release crank
1
11 201S14002 螺钉
Set screw,SM4.37
1
12 40612015 连接板
Tension release connecting rod
1
13 406S20007 螺钉
Shoulder screw,SM3.57
2
14 40605005 挑线杆部件
Upper thread take-up assy
1
15 40613002 挑线过线板
Upper thread guide
1
16 406S11015 螺钉
Screw,pan SM3.18×5
2
17 40613003 过线压板
Upper thread take-up holder
1
18 20727002 压簧
Spring
1
19 207S20003 螺钉(进口)
Screw（import）
1
20 125S11003
牙架销螺钉
Screw
1
21 40613004 过线板
Upper thread guide
1
22 201S11009 螺钉
Screw pan SM3.57-40×7
1
23 40613005 张力缓线勾
Tension release lever
1
24
201S11009 螺钉
Screw,bind SM3.57-40×8
1
25 40613006 挑线过线架
Upper thread take-up guide
1
26 40628003 垫片
Washer
1
27 406S30005 螺钉
Screw,flat SM3.57
1
28 105S11015 螺钉
Screw,pan SM4.76-32×8
1
29 300268 防护罩
Thread take-up cover
1
30 40602008 打线传动轴
T/release transmission shaft
1
31 40604017 打线曲柄
T/release connecting rod assy
1
32 40605006 连杆
Tension release link
1
33 406S20008 压脚升降连杆螺钉
Shoulder screw SM4.76
1
34 301S11007 挡圈螺钉
Screw,SM3.57
1
35 40626012 连接柱
Tension release stud
1
36 402S14006 螺钉（进口）
Screw（import）
1
37 401S11009 螺钉
Screw
1
38 40612020 压线板座
Upper therad tension bracket
1
39 40626013 松线轴
Upper thread stup assy
1
40 40627008 弹簧
Spring
1
41 40613011 压线板
Lower thread tension plate
1
42 ——— 螺母
Nut
1
43 40610010 松线偏心套
Upper thread cam
1
44 402S14006 螺钉（进口）
Screw（import）
2
From the library of Superior Sewing Machine & Supply LLC - www.supsew.com
