-20-
M1.下线过线部件（9270D）/Lower threading mechanism（9270D）
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 4061202100 底线导线安装板 Lower thread guide retainer
1
2 101S11019 推板簧螺钉 Screw,flat SM2.38
4
3 40602021 支撑板 Lower thread guide support
1
4 402S11002 螺钉 Screw,pan SM3.57-40×4
1
5 206S11002 螺钉 Screw,pan SM3.57-40×5
1
6 206S11002 螺钉 Screw,pan SM3.57-40×10
1
7 302825 过线管组件 Inglinde guide tube assy
1
8 40613029 过线管塞 Crossed the line pipe plug
6
9 201S11009 螺钉 Screw,pan SM3.57-40×8
3
10 300266 底线外盖 Front cover
1
11 40627012 底线外盖卡簧 Front cover spring
2
12 201S11009 开槽圆柱头螺钉 Screw,pan SM3.57-40×5.5
12
13 40612022 盖板固定板 Front conver hook
2
14 40612023 转动架 Hinge
2
15 40622005 防震橡胶垫 Rubber cap,4.2
2
16 40601009 左转动架 Thread guide hinge assy,L
1
17 40601010 右转动架 Thread guide hinge assy,R
1
18 101S11009 活压脚螺钉 Screw,pan SM3.57-40×6
2
19 4061301200 夹线器安装板 Lower thread guide
1
20 4061301300 过线板 Lower thread guide
1
21 40613032 大线钩 Arm thread guide M
1
22 116S17002 线勾螺钉 Screw,flat SM3.57
1
23 300267 打线凸轮盖 Thread take-up lever cover
1
24 40627009 卡簧 Spring,plate
1
25 101S11019 推板簧螺钉 Screw,SM2.38
1
26 40601011 底线转向过线板 Take-up lever bracket
1
27 40626015 打线凸轮盖销 Take-up lever cov. shaft
1
28 4061202500 凸轮导线架 Take-up lever bracket
1
29 101S11005 螺钉 Screw,pan SM3.57-40×6
2
30 40627010 导线钢丝 Lower thread guide
1
31 201S11033 螺钉 Screw,bind SM3.18-40×4
1
32 40609007 底线打线架 Thread release base
1
33 201S11005 开槽圆柱头螺钉 Scerw,pan SM3.18-40×4
2
34 40612027 底线打线板 Lower thread presser
1
35 406S11015 螺钉 Scerw,pan SM3.18-40×4
1
36 40613017 压线钢丝 Thread guide
1
37 140613002 底线导线板 Lower thread guide plate
1
38 209S11007 辅助爪螺钉 Screw,SM2.38
1
39 40928021 垫圈 Washer
2
40
P03014 销 5×12.5 Pin spring roll AW5
1
41
301S11007 挡圈螺钉 Screw,SM3.57
2
42
140613003 打线凸轮 Lower thread take-up W/S,M
1
43
409S14002 内六角平端紧定螺钉 Set Screw Socket(FT) M6×8
2
