-30-
PS专用件/Special components for PS
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 4063100400 后拖轮组件(9280)
Puller wheel asm.(9280)
1
2 301151 边盖 Top cover
1
3 40601031 抬压扳手 Wrench
1
4 40603019 调压螺母 Pressure adjusting screw
1
5 40627014 拖轮轴弹簧 Drag wheel spring
1
6 40609009 压脚轴连接块 Presser bar connecting block
1
7 40612047 连接片 Connecting piece
1
8 40602016 拖轮轴 Presser foot rod
1
9 413S13019 螺钉 M5×12 Screw M5×12
1
10 409S11013 螺钉 Screw
1
11 40603021 拉杆轴下套
Shaft tube
1
12 40602013 固定销子 Wrench pin
1
13 406S11009 螺钉 Top cover set screw
4
14 409S14001 螺钉 Puller bracket screw
1
15 406S12001 螺钉 Screw
8
16 4063502700 上轴步带轮组件 Timing belt wheel assy,upper
1
17 4061402800 后拖轮组件(9270)
Puller wheel asm.(9270)
1
