-6-
D2.抬压脚部件（9280D）/Presser bar mechanism(9280D)
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 40602003 压脚轴 Presser bar 1
2 40603005 压脚轴上套 Presser bar bush,U 1
3 40603006 压脚轴下套 Presser bar bush,D 1
4 40612006 弹簧片 Presser plate sping 1
5 40626003 销子 Pin 1
6 40612007 压板 Plate spring assy 1
7 40612008 垫片 Washer 1
8 406S30003 螺钉 Adjust screw 1
9 116S16006 螺母 Nut,2 SM4.76 1
10 406S16001 调压螺母 Presser bar lifter 1
11 40624006 钢珠 Rubber cap,20.5 1
E.带轮部件/Pulley mechanism
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 403S14005 内六角平端紧定螺钉
Hexagon Socket Set Screw With Flat Point
2
2 302824 手轮 Pulley assy
1
3 114S30001 内六角螺钉 M5×25
Socket head cap screw,M5×25
6
4 40633002 一体机电控(琦星) Integrated electronic control
1
5 409S14001 螺钉 Screw
2
6 4063502600 上轴同步带轮组件 Timing belt wheel assy,upper
1
7 40635025 传动带 Timing belt
1
8 40330025 LED 灯 LED light
1
9 12512054 齿轮供油管夹 Clamp
3
10 40928020 垫圈 Washer
4
11 207S11019 螺钉 M4×7.5 Screw,M4×7.5
6
12 303054 同步带罩壳 Belt housing
1
13 40635024 下轴同步带轮 Timing belt wheel assy,lower
1
14 116S14005 螺钉 Screw
2
15 40633003 电机 Electric motor
1
16 13628013 电机垫圈 Motor washer
4
17 W03002 波形垫片 Washer
4
18 40612079 电机罩壳 Motor casing
1
19 S05048 螺钉 M4×10 Screw,M4×10
6
20 S05083 螺钉 M5×30 Screw,M5×30
2
