-28-
2PL/PL专用部件/Special components for 2PL/PL
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 4061402700 上拖轮组件 Upper plastic wheel ass.
1
2 4061402500 下拖轮组件 Lower plastic wheel ass.
1
3 40603019 调节螺母 Adjusting screw
1
4 40627014 拖轮轴弹簧 Presser spring
1
5 40602017 长轴 Long shaft
1
6 40603016 铜套(后) Long shaft tube(back)
1
7 301151 边盖 Top cover
1
8 40601031 抬压扳手 Lift pressure wrench
1
9 40602013 固定销子 Wrench pin
1
10 4060402400 拉杆组件 Joint bearing base
1
11 40619003 上剪线刀 Top cutter
1
12 40619005 下剪线刀 Bottom cutter
1
13 40609009 压脚轴连接块 Presser bar connecting block
1
14 413S13019 螺钉 M5×13 Screw，M5×13
1
15 40612047 连接片 Connecting piece
1
16 40603020 挡圈 Block ring
2
17 S05004
内六角圆柱头螺钉 M5×14
Set Screw Socket,M5×14
2
18 40605010 偏心调节杆 Adjusting rodneiliu
2
19 40612045 连接板 Thread tension connecting rod
1
20 40612048 刻度指示板 Dial indicating piece
2
21 401S16002 螺帽 Screw
2
22 406S20010 偏心调节杆轴位螺钉 Adjusting rod screw
1
23 40610012 主轴偏心轮 Eccentric wheel
1
24 B07036 滚针轴承 K28×33×13 Needle bearingK28×33×13
1
25 40605009 主轴连杆 Connecting rod
1
26 40612050 固定板 Eccentric wheel piece
1
27 40603013 套筒 Long shaft tube
1
28 40622016 橡皮挡板 Rubber plug
2
29 403S11017 复合槽圆柱头螺钉 Blade set screw
2
30 40602016 拖轮轴 Presser foot rod
1
31 101S11006 支针螺钉 Block piece set screw
2
32 403S14004 螺钉 Block ring set screw
4
33 116S14005 螺钉 Screw
1
34 409S14001 螺钉 Screw
1
35 4061400800 拖轮组件 Upper puller assy
1
36 4061401900 拖轮组件 Puller assy
1
37 40603021 拉杆轴下套
Shaft tube
1
From the library of Superior Sewing Machine & Supply LLC - www.supsew.com
