-8-
F.送料部件/Feed mechanism
序号 件号 数量
REF.NO. Part NO. Qty
1 4061000100 送料凸轮组件 Eccentric wheel assy,M
1
2 40627003 弹簧 Twist spring
1
3 406S20009 螺钉 Screw,M3
1
4 403s14004 螺钉 Set screw,socket M6×6
2
5 40609003 送料滑块 Eccentric wheel sleeve
1
6 40610006 送料偏心轮 Eccentric wheel with screw,M
1
7 403S14004 螺钉 Set screw,socket SM6.35
2
8 40606001 送料牙架 Feed bar slide block assy
1
9 40609004 牙架滑块 Feed bar slider
1
10 40604004 送料曲柄 Feed lifting connencting shaft
1
11 40626004 曲柄销 Feed lifting rock shaft
1
12 409S15002 螺钉 Set screw socket SM5.95
1
13 40626005 送料偏心销 Feed bar eccentrics shaft
1
14 10122010
O型圈6×1.8
O ring,P6
1
15
409S15002
左销螺钉
Set screw,socket SM5.95
1
16 40626006 针距调节销 Push button
1
17 40627004 弹簧 Spring
1
18 10122010
O型圈4×1.8
O ring,P5
1
19 20128025
垫片
Washer,plain S4.76
1
20 H05012
挡圈
Retaining ring,E4
1
21 40610007 送料偏心轮 Eccentric wheel with screw,H
1
22 4061001100 送布凸轮组件 Eccentric wheel assy,H
1
23 40123008 油隔热板
1
24 40610003 针距调节凸轮 Needle adjustment cam
1
25 40626035 弹簧销 Spring pin
1
26 40625001 止动板 Stop plate
1
27 40610002 止动凸轮 Stop cam
1
28 40610014 止动凸轮 Stop cam
1
名称 Description
Oilproof wool felt
From the library of Superior Sewing Machine & Supply LLC - www.supsew.com
