-12-
J.下轴部件/Lower shaft mechanism
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1 40601059 传动连接块 2 Drive connecting block 2 1
2 403S14005 内六角平端紧定螺钉
Set Screw Socket(FT) M6×8 4
3 40322028 减震橡胶 Shock absorbing rubber 1
4 40301023 传动连接块 Drive connecting block 1
5 40311302 叶轮 Impeller 1
6 402S11023 螺钉 Screw,pan SM4.76-32×10 3
7 40602029 下轴 Lower shaft 1
8 101S11023 送料调节器轴端螺钉
Screw,SM4.37 1
9 B03003 轴承6200Z Ball bearing,6200Z 1
10 20622019 油封 Oil seal 1
11 40608005 轴套 Shaft sleeve 1
12 40608002 下轴挡圈 Lower shaft collar 1
13 409S14002 挡圈螺钉 Set screw,SM4.37 2
14 H01004 卡簧42 Retaining ring,C42 2
15 B01008 轴承 6302ZZ Ball bearing,6320ZZ 2
16 40612002 轴承盖 Bearing presser 1
17
402S11023 螺钉
Screw,pan SM4.76-32×10
3
