-14-
K.弯针轴部件/Looper mechanism
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1
400138
离合滑块
Eccentric wheel sleeve
1
2
40605003
弯针离合叉
Lopper feeding fork assy
1
3 201S11023
螺钉
Screw,SM4.37
1
4
40602005
弯针离合轴
Lopper feeding fork shaft
1
5 40601006
弯针离合轴座
Lopper fork shaft bracket
1
6
406S30013
螺钉
Screw,SM4.76
1
7
40626022
曲柄连接销
Looper link shaft
2
8 406S30004
螺钉 Screw,SM2.38
2
9 40604012
离合曲柄 Looper lever
2
10 40604019
离合架 Looper holder
1
11 40626009
销子 Pin
1
12 40605004
曲柄 Lever
1
13 40609010
曲柄滑块 Lever slider
1
14
40626010
销子 Pin
1
15
406S11004
螺钉 Screw,SM4.37
1
16
O01016
O 型圈 6×1.8 O ring6×1.8
1
17
409S15004
螺钉 Set screw,SM5.95
1
18
40608003
离合架销挡圈 Block plate
1
19
409S14002
内六角平端紧定螺钉
Set Screw Socket(FT) M6×8
2
20
O01004
O 型圈 4×1.8 O ring 4×1.8
1
21
402S14006
螺钉 Screw,SM5.95
1
22
4060401500
弯针摆杆 Looper shaft link assy set
1
23
201S11023
螺钉 Set screw
1
24
409S16020
螺母 Nut,SM5.95
1
25
W03026
波形垫片 5.8 Washer
1
26
40603007
弯针轴后套 Looper shaft bush,F
1
27
40603008
弯针轴前套 Looper shaft bush,B
1
28
40608004
挡圈 Looper shaft set collar
1
29
201S11023
螺钉 Screw,pan SM4.37-40×8
1
30
40612012
下仓盖 Front feed arm cap
1
31
40622010
下仓盖垫 Packing
1
32 101s11009 活压脚螺钉 Screw,SM3.57
1
33
300263
下轴前盖 Ball bearing
1
34
40622011
垫片 Packing
1
35
401S11003
螺钉 Screw,pan SM3.57-40×5
4
36
207S13002
放油螺钉 Screw
2
37
40222027
给油帽衬垫 O ring
1
38
40602006
弯针轴 Looper shaft
1
39
40610008
抬牙偏心轮 Eccentric wheel
1
40
409S14002
内六角平端紧定螺钉
Set Screw Socket(FT) M6×8
2
41
40610009
抬牙偏心轮 Eccentric wheel
1
