-16-
L1.上线过线部件（9270D）Lower shaft mechanism
序号
REF.NO.
件号
Part NO.
名称 Description
数量
Qty
1
4061201400 面线导线支架板 Upper thread guide
1
2
40613001 过线勾 Thread guide
1
3
402S11022 螺钉 Screw
1
4
406S11018 螺钉 SM3/16×28 Screw,SM3/16×28
1
5
300264 面线松线器座 Upper thread tension bracket
1
6
4061304000 夹线器组件 yarn trapper assy
1
7
40602007 松线轴 Tension release shaft
2
8
406S30007 螺钉 Set screw,SM4.37
2
9
201S16003 螺母 Nut,SM4.37
1
10
40604016 松线曲柄 Tension release crank
1
11
201S14002 螺钉 Set screw,SM4.37
1
12
40612015 连接板 Tension release connecting rod
1
13
406S20007 螺钉 Shoulder screw,SM3.57
1
14 40605005 挑线杆部件 Upper thread take-up assy
1
15 40613002 挑线过线板 Upper thread guide
1
16 406S11015 螺钉 Screw,pan SM3.18×5
2
17 40613003 过线压板 Upper thread take-up holder
1
18 20727002 压簧 Spring
1
19 207S20003 螺钉(进口) Screw（import）
2
20 125S11003 牙架销螺钉 Screw
1
21 40613004 过线板 Upper thread guide
1
22 201S11009 螺钉 Screw,pan SM3.57-40×7
1
23 40613005 张力缓线勾 Tension release lever
1
24 201S11009 螺钉 Screw
1
25 40613006 挑线过线架 Upper thread thake-up guide
1
26 40628003 垫片 Washer
1
27 406S30005 螺钉 Screw,flat SM3.57
1
28 300268 防护罩 Thread take-up cover
1
29 406S11009 螺钉 Screw pan SM4.76-32×8
2
30 4061204400 面线导线支架板组件 Upper thread guide assy
1
