Jackle tecMIG 450 - Page 59

tecMIG 450/600
Operating manual Page 57
Nr. Bezeichnung Designation
Nummer / Number
30 Tankdeckel Schraubgewinde Filler cap screw thread 308.400.010
31 Kunststofftank K2010 Plastic Tank K2010 715.044.353
32 Gasschlauch Gastube 709.150.001
33 Kabelverschraubung M25x1,5 Gland M25x1,5 420.025.001
Mutter M15x1,5 Nut M25x1,5 420.025.002
Netzkabel 4x4mm² 5m (tecMIG 450) Main cable 4x4mm² 5m (tecMIG 450) 704.040.014
Netzkabel 4x6mm² 5m (tecMIG 600)
Main cable 4x6mm² 5m (tecMIG 600)
704.060.022
34 Kette 24 Glieder Chain 24 chain links 101.097.010
35 Flaschenboden 250mm (tecMIG 450) Bottle plate 250mm (tecMIG 450) 715.044.333
Flaschenboden 300mm (tecMIG 600) Bottle plate 300mm (tecMIG 600) 715.044.370
36 Rad 250mm (tecMIG 450) Wheel 250mm (tecMIG 450) 301.250.009
Starlockkappe 25mm Star lock cap 25mm 301.025.010
Rad 300mm (tecMIG 600) Wheel 300mm (tecMIG 600) 301.300.001
Starlockkappe 25mm Star lock cap 25mm 301.025.010
37 Wasserdurchflußmesser Water flow meter 444.000.001
38 EMV Filter tecMIG 450 EMC Filter tecMIG 450 600.028.003
EMV Filter tecMIG 600 EMC Filter tecMIG 600 600.032.305
39 Thyristorhalteblech – tecMIG 450 Thyristor bracket – tecMIG 450 101.044.331
Thyristorhalteblech – tecMIG 600 Thyristor bracket – tecMIG 600 101.044.328
40 Grundlastwiderstand 82Ohm Basic resisitor 82Ohm 452.082.015
41 Pumpenkühleinheit komplett Pump cooling unit complete 705.044.322
Wärmetauscher einzeln Heat exchanger solo 521.001.501
42 Wasserpumpe mit Lüfterrad Water pump with cooling fan 456.220.300
43 Lenkrolle 160mm (tecMIG 450) Caster roller 160mm (tecMIG 450) 301.160.001
Lenkrolle 200mm (tecMIG 600) Caster roller 200mm (tecMIG 600) 301.200.016
44 Steuertrafo 42V, 160VA Auxiliary transformer 42V, 160VA 462.042.016
45 Drosselmodul MC – CHO Choke module MC – CHO 600.044.035
46 Stromwandler MC – ISENSE Current transformer MC - ISENSE 600.044.016
Messingbolzen SW14 100mm Brass bolt SW14 100mm 357.011.001
47 Thyristorsatz 450A (tecMIG 450) Thyristor 450A (tecMIG 450) 460.450.001
Thyristorsatz 600A (tecMIG 600) Thyristor 600A (tecMIG 600) 460.600.001
Thermoschalter 90°C Öffner Thermo switch 90°C opener 445.080.004
48 Drossel tecMIG 450 Choke tecMIG 450 706.044.001
Drossel tecMIG 600 Choke tecMIG 600 706.044.005
50 Schraubbuchse 17-polig Screw bush 17-pole 410.017.099
Kabelstecker einzeln für Buchse Single cable plug for female 410.017.100
51 Massebuchse BEB 35-50 Built-in tip jack BEB 35-50 422.031.024
Tucheldose 7-polig mit PE Tuchel bush 7-pole with earth 410.007.092
52 Schnellkupplung DN5 – G1/4 I Quick Coupling DN5 – G1/4 I 355.014.007
53 Kondensator 2µF (tecMIG 450) Capacitor 2µF (tecMIG 450) 453.450.003
Kondensator 5µF (tecMIG 600) Capacitor 5µF (tecMIG 600) 453.400.013
54 Lüfterblech 300 (tecMIG 450) Fan mounting plate (tecMIG 450) 715.044.310
Lüfterblech 350 (tecMIG 600) Fan mounting plate (tecMIG 600) 715.044.307
55 Lüfter 300mm (tecMIG 450) Fan 300mm (tecMIG 450) 450.300.020
Lüfter 350mm (tecMIG 600) Fan 350mm (tecMIG 600) 450.350.010
56 Schweißtrafo tecMIG 450 Welding transformer tecMIG 450 706.044.002
Schweißtrafo tecMIG 600 Welding transformer tecMIG 600 706.044.006
