tecMIG 450/600
Operating manual Page 62
Nr. Bezeichnung Designation
Nummer / Number
130 Klapphaube DVK 4 – 2010 Flap Case DVK 4 – 2010 715.013.210
131 Handgriff quer DVK 4 -2010 Across handle DVK 4 – 2010 715.013.127
132 Kunststoffgriff klein Hand grip small 305.044.002
Schraube Torx PT60 Screw Torx PT60 271.060.001
133
Zentralbuchse lang DVK4-2010 central adapter long DVK4-2010 425.133.010
Drahtführungsrohr 124 mm Wire guide tube 124mm 425.124.001
Isolierflansch für Binzel Zentraladapter insulating flange for Binzel adapter 425.501.004
134 Verschlusskupplung DN 5 - G 1/4 I Rapid action coupling DN 5 - G ¼ I 355.014.007
PVC Scheibe rot PVC washer red 101.011.047
PVC Scheibe blau PVC washer blue 101.011.048
135 Haubeneck DVK4 - 2010 Triangle cover left DVK 4 – 2010 715.013.212
136 Scharnier 40x40mm Hindge 40x40mm 303.056.003
137 Scharnierblech DVK 4 – 2010 Hindge cover DVK 4 – 2010 715.013.211
138 Siehe 132 Look 132
139
Steuerbox MC 1
Control unit MC 1
851.044.001
Steuerbox MC 2 Control unit MC 2 851.044.002
Feinsicherung T 6,3 A Steuerplatine fine wire fuse T 6,3 A for control board 464.036.010
Drehknopf 28mm Turning knob 28mm 305.042.010
Deckel für Knopf Cover 28mm 305.042.011
140 Tucheldose 7-polig Tuchel socket 7-pole 410.007.111
141 Seitenblech rechts DVK 4 – 2010 Right side cover DVK 4 – 2010 715.013.213
142 Drahtaufnahmedorn wire holding arbor
306.050.001
143 Lastöse M12
Nut M12 D582 M12 V
144 Motorisolierplatte DVK 4 - 2010 Motor insulation plate DVK 4 – 2010
101.013.039
145 Lenkrolle D75x22 mm castor roller, diam. 75 x 22 mm
301.075.007
146 Gasdämpfer Gas struts
303.013.010
147
Drahtvorschubmotor 140W 42V 4
Rollen
wire feed motor with 4-roller feed 140
W, 42V
454.140.023
DV Rolle 0,8-1,0 mm
wire feed roll 0.8 - 1.0 for 4-roller feed
454.010.024
DV Rolle 1,0-1,2 mm
wire feed roll 1.0 - 1.2 for 4-roller feed
454.012.025
DV Rolle 1,6 mm gerändelt
wire feed roll 1.6, knurled type, 4-roller
feed
454.016.026
DV Rolle glatt – gerändelt
wire feed roll, plain/ knurled, 4-roller
feed
454.000.027
148 Platine MC - DVV PCB MC - DVV 600.044.030
149 Magnetventil NW 2,5 / 42V G 1/8 solenoid valve NW2,5 / 42V G1/8
465.018.009
150 Anschlußblech Innenanschluß Gusset plate for inside connection 715.042.041
151 Stromanschlußplatte Plate for current connection 703.011.006
