44
200 Series Technical Manual
7610-100-45-00 Rev. E (02/10/2006)
SECTION 6: PARTS SECTION
WASH & RINSE ARM/MANIFOLD ASSEMBLIES
Top Wash & Rinse Manifold Assembly
05700-001-25-52
Bottom Wash & Rinse Manifold Assembly
05700-001-25-53
Manifold Gasket
2 per
05330-500-18-00
Manifold Spanner Nut
05700-001-22-56
Hose, Rinse Manifold Hose
05700-001-26-50
Connects with 2 of the following:
Clamp, Hose, 11/16” - 1 1/4”
04730-002-18-40
Hose, Top Manifold Pump
05700-001-22-93
Connects with 1 of the following:
Clamp, Hose, 1-5/16” - 2-1/4”
04730-719-01-37
To Next Page
