200 Series Technical Manual
7610-100-45-00 Rev. E (02/10/2006)
SECTION 1: SPECIFICATION INFORMATION
DIMENSIONS
C
D
C
A
3 1/2”
32”
D
15 1/2”
39.4cm
A
B
2 7/8”
7.3 cm
25 1/2”
64.7cm
56 3/4”
144.1 cm
10 3/4”
27.3 cm
21 1/8”
53.6 cm
3 3/4”
9.5 cm
15 1/2”
39.4 cm
A
B
2 7/8”
7.3 cm
13 1/2”
34.2 cm
75 1/2”
191.7 cm
64”
162.6 cm
17 3/4”
45.1 cm
34”
86.4 cm
21 1/8”
53.7 cm
25 5/16”
64.3 cm
FRONT VIEW
RIGHT SIDE VIEW
TOP VIEW
FRONT
TOP VIEW
CORNER CONVERSION
E
LEGEND:
A- Drain 1 1/2” NPT
B- Water inlet 3/4” NPT
C- Electrical connection
D- Standard wall clearance, with dish table 4”
E- Model 200B booster tank location
16 1/8”
40.9 cm
25 1/4”
(64.1 cm)
30”
76.2 cm
25 1/4”
64.1 cm
