Jackson AVENGER HT-E - Electrical Requirements and Configurations

3
07610-004-04-18-R
All electrical ratings provided in this manual are for reference
only. Always refer to the machine data plate to get exact electrical
information for this machine. All electrical work performed on
machines should be done in accordance with applicable local,
state, territorial, and national codes. Work should only be
performed by qualied electricians and authorized service agents.
Note that all electrical wiring used must be rated, at a minimum,
for 212°F (100°C) and that only copper conductors must be used.
Where applicable, heating element amperage draws have been
adjusted for the assumed input voltage. The manufacturer
assumes incoming voltages will be either 208 or 230 volts.
Some heating elements used in the machines are rated for other
voltages, such as 240 volts. Always verify the amperage draw of
the machine in operation when sizing circuit protection.
If the dishmachine is equipped with the optional rinse heater, note
that the rinse heater might have its own electrical connection and
therefore require a separate service. Amperage loads for motors
and heaters are indicated on the machine data plate.
The electrical congurations are as follows:
Available Electrical Characteristics:
• 208 V, 60 Hz, Single-phase
• 230 V, 60 Hz, Single-phase
• 480 V, 60 Hz, Three-phase
Available Wash Tank Heaters:
• 14 kW
Available Rinse Tank Heaters:
• 2 kW for top tank
• 2 kW for bottom tank
AVENGER HT-E
Electrical Characteristics
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
VOLTS 208 230 480
PHASE 1 1 3
FREQ 60 60 60
WASH
MOTOR
AMPS
5.0 A 5.0 A 1.3A
DRAIN
PUMP
0.6 A 0.6 A 1.0A
WASH
HEATER
AMPS
15.9 A 17.4 A 5.0A
RINSE
HEATER
AMPS
15.9 A 17.4 A 5.0A
TOTAL
LOAD
36.8 A 39.8 A 11.3A
NOTICE
i
Imbalanced wild leg
goes to L3.
