29
07610-004-04-18-R
TERMINAL BLOCK BOX ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Power Connection Decal 09905-011-47-35
2 1 Terminal Block Box 05700-003-27-69
1 Terminal Box Cover (not shown) 05700-003-27-70
3 1 Strain Relief 05975-003-37-56
4 1 Terminal Block Track 05700-000-43-60
5 2 Terminal Block 05940-500-02-19
6 2 10-24 Lock Nut 05310-373-01-00
7 1 Copper Conductors Decal 09905-011-62-72
8 1 Ground Lug 05940-200-76-00
6
7
5
4
8
1
3
2
