Jackson AVENGER HT-E - 480 V Control Box Diagram

36
07610-004-04-18-R
PARTS
480 V CONTROL BOX
PART NUMBER
DESCRIPTIONQTY
ITEM
04320-004-09-56PERIPUMP, 36 RPM 24VDC21
05945-003-75-22
CONTACTOR, 24VDC, 460V MAX, 5HP
42
05945-003-75-17OVERLOAD, 10-14A, 600VAC MAX, (MTO3P)13
05940-200-76-00
LUG,LAMA214Q/PANDUIT GROUND
14
05920-011-72-89HOLDER, BM6031SQ SINPO FUSE BUSSMAN17
05310-373-01-00
NUT, LOCK10-24 S/S HEX W/NYLON IN
78
05920-011-72-88FUSE, 1/2 AMP FNQ-R-1/2 BUSSMAN110
05940-002-31-31 111
05940-002-31-33
CONNECTOR, 2060364A SQ RECEPTACLE112
05305-171-02-00
SCREW 3/8 PAN HEAD
413
05975-011-65-51FITG.3219 .25/.546 LIQTITE114
05975-003-37-56
STRAIN RELIEF,1857 HEYCO RDD201
115
05700-004-09-28F-BRACKET, CTRL BOX REST116
05700-011-88-01
WEAR BUTTON, .50 DIA UHMW
117
05305-002-74-99SCREW, 6-32X1/2" SST FHMS818
04730-011-39-01CLAMP, 5/8 NYLON W6NY-625-9-M T&B119
05305-173-26-00SCREW, 10-32 X 3/8 PHILLIPS PAN HD1820
057
00-004-11-34W-INNER PANEL, AVENGER HT-E CONT. BOX121
05700-004-11-32W-CONTROL BOX, AVENGER HT-E-480V122
05700-004-11-37F-DIN RAIL, AVENGER HT-E 2"123
05700-004-11-36F-DIN RAIL, AVENGER HT-E 5-3/4"124
05700-004-11-39W-COVER, CONT. BOX U-COUNTER 480V125
05950-011-50-70TRANSFORMER 150 VA 50/80 H z126
NUM REVISION
CONTROL#
ORIG
DRWN
BY
DATE
PARTS LIST
REV:
PART NO:
SCALE:
TITLE:DRAWN BY:
DATE:
DATE:
DATE:
CHECKED BY:
APPROVED BY:
PART TO BE FREE FROM ALL BURRS AND SHARP EDGES
DO NOT SCALE DRAWING
THIS PRINT IS THE PROPERTY OF JACKSON WWS,INC. AND IS SUBJECT TO RECALL AND
RETURN ON DEMAND. ANY USE, DISCLOSURE, REPRODUCTION, DUPLICATION, TRACING,
OR USE OF INFORMATION CONTAINED HEREIN IN ANY MANNER DETRIMENTAL TO
THE
INTEREST OF JACKSON WWS,INC. IS FORBIDDEN. ALL RIGHTS OF DESIGN RESERVED.
R.M.I. NO:
GAUGE:
MATERIAL:
USED ON:
NEXT ASSM:
3D MODEL?
TOLERANCES
UNLESS OTHERWISE SPECIFIED
DIMENSIONS IN INCHES
3 PL DECIMALS 
2 PL DECIMALS 
FRACTIONS 1/32
ANGLES
1/2
LET
REVISION
CONTROL#
ORIG
DRWN
BY
DATE
05700-004-11-35
A-CONTROL BOX, SLIDE 480V
B.GAMBREL
2/10/2014
N/A
N/A
N/A
AVENGER HT-E
05700-004-11-40
Yes
A
C
W
O
#
;
2
3
26
2
7
10
1
1
1
1
2
3
4
2
5
6
ITEM QTY DESCRIPTION PART NUMBER
1 2 Peri-pump, 36 RPM, 24 VDC 04320-004-09-56
2 4 Contactor, 24 VDC, 460 V Max, 5 HP 05945-111-60-07
3 1 Fuse Holder 05920-011-72-89
4 1 Fuse, 1/2 A, FNQ-R-1/2 Bussman 05920-011-72-88
5 1 Overload, 10=14 A, 600 VAC Max, 5 HP 05945-111-60-08
6 1 Transformer 150 VA, 50/80 Hz 05950-011-50-70
