Jackson AVENGER HT-E - Operation; Pre-Operation Checks and Preparation; Power Up and Wash Tub Filling

10
07610-004-04-18-R
OPERATING INSTRUCTIONS
OPERATION
Before operating the unit, verify the following:
1. Strainers are in place and clean.
2. Wash and rinse arms are screwed securely into place and end-caps are tight.
3. Wash and rinse arms rotate freely.
4. Chemical levels are correct.
To energize the unit, turn on the power at the service breaker. The voltage should
have been previously veried as correct. If not, the voltage must be veried before
energizing the unit.
1. Verify the standpipe is installed correctly (seated vertically in the center of the
wash sump).
2. Close the door.
3. Press the “Power” button.
4. The unit will automatically begin the fill cycle.
5. Once the wash tub is filled, the unit is ready for operation.
6. Wait for wash temperature to reach at least 155 °F before operating the unit.
PREPARATION
POWER UP
FILLING THE
WASH TUB
