41
07610-004-04-18-R
WASH & DRAIN MOTOR ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Sump 05700-004-02-94
2 1 Sump Strainer 05700-004-03-73
3 1 Stand Pipe 05700-004-04-40
4 1 Manifold Gasket 05330-002-34-77
5 2 Wash Arm Assembly 05700-021-39-23
6 4 Wash Arm End-cap 05700-011-35-92
7 1 Wash Halo 05700-004-03-22
8 39 Locknut, 1/4-20 Hex w/Nylon Insert 05310-374-01-00
9 1 Wash Manifold 05700-004-08-96
10 1 Pump Assembly w/Mounting Bracket and Hoses 05700-004-04-04
11 1 Drain Pump 04730-003-91-41
12 1 Drain Hose 05700-004-08-21
13 3 Clamp, Reg. Range 1 1/16" to 2" 04730-719-18-00
To Next Page
