45
07610-004-04-18-R
PLUMBING ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Valve, 1/2" 04810-003-71-56
2 1 Union, 1/2" x 1/2" Brass 04730-003-62-44
3 1 Nipple, 1/2" Close Brass 04730-207-15-00
4 1 Nipple, 1/2" x 4" NPT Brass 04730-207-04-00
5 1 Adapter, 1/2" Fitting, Male 04730-011-59-53
6 1 Elbow, 1/2" S. CU to FTG 04730-406-31-01
7 1 Hose Adapter 04720-004-24-68
8 1 PRV, 1/2" (Optional) 04820-004-09-37
9 1 Elbow, 90 Degree 1/2" Street Brass 04730-206-08-00
10 2 Adapter, Male (CU to MSPS) 04730-401-03-01
11 1 Copper Tube, 1/2" x 19.5" Long 05700-011-59-84
12 1 Vacuum Breaker, 1/2" Brass 04820-003-06-13
13 1 Fitting, 1/4" Brass Nut/Sleeve 05310-924-02-05
14 1 Rinse Injector 05700-004-08-28
15 1 Pressure Transducer 05945-004-17-01
16 1 Harness, Pressure Transducer 05999-004-21-58
17 1 Fitting, Outlet Elbow 04820-111-51-18
18 1 Nut, Tube 1/8" PP 04730-011-59-45
19 1 Check Valve 04820-111-51-14
20 1 Bushing, 1/4" x 1/8" 04730-003-05-61
To Next Page
