WASH PUMP ASSEMBLY
PARTS
** Models with 480 V Control Box
3
ITEM QTY DESCRIPTION PART NUMBER
1 1 Hose 1 1/4" x 8" 05700-004-08-21
2 1 Sump 05700-004-02-94
3 2 Clamp, 1 1/16" to 2" 04730-719-18-00
4 1 Drain Pump 04730-003-91-41
5 2 Elbow, Hose Barb Drain 04720-004-20-12
6 1 Drain Hose, 8" 04720-111-39-73
7 1 Drain Hose, 3" 04720-111-39-73
8 5 Clamp, 13/16" to 1 1/2" 04730-719-06-09
9
1 Wash Pump 06105-004-24-79
1 ** 480 V Wash Pump 06105-004-07-54
10 1 Motor Mount Brace 05700-004-01-64
11 1 Elbow, Pump to Wash Manifold 04720-004-02-73
12 2 Lockwasher, 3/8" 05311-276-01-00
13 2 Nut, Hex 3/8-16 x 1 Long 05310-276-01-00
14 2 Bolt, Hex 3/8-16 x 1 Long 05305-276-03-00
15 1 Bottom Wash Dishcharge Hose 05700-001-22-92
16 1 O-ring, Viton 05330-400-05-00
17 1 Sump Strainer 05700-004-03-73
18 1 Standpipe 05700-004-04-40
NOTE: Items 6 and 7 are the same part made from raw hose material that is cut to order. When ordering, please
specify the length that is needed.
