Jackson DishStar LT - H Control Panel

07610-004-37-13-R
33
1
2 3
4
5
6
8
9
ITEM QTY DESCRIPTION PART NUMBER
1 2 Contactor, 110 V 05945-109-05-69
2 2 Relay, Omron 05945-002-47-41
3 3 Open/Closed Bushing 05975-003-35-21
4 1 Control Panel Weldment 05700-004-35-76
5 1 Universal Timer 05945-003-75-23
6 4 Screw, 10-32 x 1" 05305-002-19-42
7 1 Thermostat Plate 05700-004-37-67
8 1 Thermostat, Electric 06685-004-17-27
9 7 Screw, 10-32 x 3/8" 05305-173-12-00
7
LT-H CONTROL PANEL
PARTS
