Jackson DishStar LT - H Optional Heater Components

64
07610-004-37-13-R
ITEM QTY DESCRIPTION PART NUMBER
1 1 Thermostat Bracket 05700-004-36-37
2 1 High Limit Thermostat 05930-004-33-15
3 1 Probe Bracket 05700-004-38-45
4 1 Wash Heater, 115 V, 1.5 kW 04540-004-33-76
5 4 Lockwasher, Split, 5/16" 05311-275-01-00
6 4 Nut, Hex 5/16-18 05310-275-01-00
7 1 Wash Heater Gasket 05330-011-61-34
8 1 Thermostat, Electric Dual 06685-004-17-27
1
2
3
4
6
5
7
PARTS
LT-H OPTIONAL HEATER COMPONENTS
8
